Conexpro GNT-P2913AB, PoE Singlemode media converter, 1Gbps, kit

Conexpro GNT-P2913AB, PoE Singlemode media converter, 1Gbps, kit
With its appearance and aluminum construction, a completely unique Gigabit Singlemode WDM media converter kit for a distance of up to 3 km supporting power supply via PoE and DC jack. Media converters are designed to transform the signal from an optical Singlemode fiber (9 / 125um) with 1x SC connector to a metallic LAN cable with a speed of up to ... More information
ManufacturerConexpro
PNGNT-P2913AB
EAN0710497563093

Product description

With its appearance and aluminum construction, a completely unique Gigabit Singlemode WDM media converter kit for a distance of up to 3 km supporting power supply via PoE and DC jack. Media converters are designed to transform the signal from an optical Singlemode fiber (9 / 125um) with 1x SC connector to a metallic LAN cable with a speed of up to 10/100/1000 Mbps and vice versa. The converters support the wavelength 1310 / 1550 nm (side A) and 1550 / 1310 nm (side B). Each converter can be powered either via DC jack (12 to 48V DC) or 802.3af PoE. In the package you will find only 2 converters without power adapters.

Do you have a question or comment about this product?

Technical parameters

Optics

For cable typeSingle Mode
Transmission speed1 Gbps
Wavelength - Tx/Rx [nm]1310 / 1550, 1550 / 1310
Distance [km]3

Connectors and interfaces

Optical Connectors(1) SC
LAN speed(1) 10/100/1000Mbps
Optical interfaces(1) 1000Mbps

Power

Power typePoE, DC connector
Max. power consumption [W]3
Power via connector/terminal12 .. 48V DC
Power over Ethernet802.3af

Physical characteristics

PurposeIndoor
Operating temperature [°C]-30 up to 60
Height [mm]20
Width [mm]24
Depth [mm]80
