Reverse Gigabit PoE switch without management with 16 Gigabit LAN ports and two optical SFP ports enables power supply directly up to 15 client devices on ports 1 to 15 using passive PoE (12-57 V DC, 4/5+ and 7/8-) or via the DC jack on the back. Port 16 serves as an uplink (max. 1A) for a Wi-Fi unit on the roof (MikroTik, Ubiquiti, ...), which it ... More information
ManufacturerConexpro
PNGPOE-REVS-16
EAN0710497563079
Where to buyAsk a question

Product description

Reverse Gigabit PoE switch without management with 16 Gigabit LAN ports and two optical SFP ports enables power supply directly up to 15 client devices on ports 1 to 15 using passive PoE (12-57 V DC, 4/5+ and 7/8-) or via the DC jack on the back. Port 16 serves as an uplink (max. 1A) for a Wi-Fi unit on the roof (MikroTik, Ubiquiti, ...), which it supplies with the same voltage as the entire switch. It features a robust metal design that ensures high durability, and reliably serves for network connections, ideal for larger installations.

Package contents

  • Device
Do you have a question or comment about this product?
Ask a question

Technical parameters

Connectors and interfaces

LAN speed(16) 10/100/1000Mbps
Optical interfaces(2) 1000Mbps

Power

Power typePoE, DC connector
PoE Input ports15
PoE typePoE-Out + PoE-In
PoE-Out standardsPassive 24V, Passive 48V, Passive 54V
PoE Out ports1
Max. power consumption [W]2
Power via connector/terminal9 .. 52V DC
Power over Ethernet12 .. 57V DC

Physical characteristics

DesignDesktop
PurposeIndoor
FansWithout fan
Chassis designPlastic
Operating temperature [°C]-10 up to 55
Height [mm]38
Depth [mm]132
Width [mm]262

General

Switchning capacity [Gbps]36
MAC address table8000
